The Latest Hardware Mods For The Delco ECM and PCM

Post by **VL400** » Fri Apr 03, 2009 7:15 pm

Now that some initial testing is complete here are some pictures of some new products that will be available very shortly. Combine these hardware modifications with some software for the ECM/PCM and a laptop, and you can turn any ECM or PCM from VN to VX into a realtime tuning capable device.

: Realtime_All.jpg (104.23 KiB) Viewed 7358 times

NVRAM Conversion for VN to VS (Excluding Ecotec) ECMs and PCMs...with this device plugged in you have dual maps, writable calibration data for real-time tuning, cyl select by jumpers instead of having to search for a memcal that matches the number of cylinders the engine has, customisable knock sensor filtering by just soldering on any filter board - this means you can easily run say a V6 knock filter board on a V8, this is important for people running non-GM engines that want to keep accurate knock filtering and many other features...

: NVRAM_128k.jpg (97.69 KiB) Viewed 7358 times

NVRAM Conversion for VS Ecotec and later PCMs... with modified software for the PCM this device allows for writable calibration data over ALDL on VS Ecotec and later sequential PCMs...

: NVRAM_PCM.jpg (32.95 KiB) Viewed 7358 times

Communications board to enable 8192baud ALDL on VN and VP ECMs...sick of 160 baud ALDL and cant find a VR/VS manual ECM? This will allow 8192 baud data from the ECM to a PC via a standard serial cable. No special ALDL cable required once this is installed...

: 808Comms_Rev3.jpg (67.62 KiB) Viewed 7358 times

Stay tuned for pricing, availability and software

Post by **antus** » Fri Apr 03, 2009 7:44 pm

mmmmm tasty

cant wait to get get my hands on one!

Post by **delcowizzid** » Fri Apr 03, 2009 7:49 pm

very nice definatly a must have product will speed up tuning tremendously.

Post by **Holden202T** » Fri Apr 03, 2009 9:47 pm

i must say now that i've seen the completed product the black board sure does look alot better than the usual green

i like the rx ands tx leds too.... i assume the jumper on the vs ecotec board is for switching calibrations ?

Post by **delcowizzid** » Fri Apr 03, 2009 9:51 pm

im just guessing the jumper is like a write protect jumper as you wont fit more than one bin on there.

Post by **Holden202T** » Fri Apr 03, 2009 9:56 pm

unless you have a 2048 or bigger nvram

Post by **antus** » Fri Apr 03, 2009 10:46 pm

It looks like it says W_EN under it (Write ENable) Very useful feature to have when your developing software. saves trashing your nvram too often when your developing stuff like antusprom

Post by **Holden202T** » Fri Apr 03, 2009 10:48 pm

wish my current rt board had that

Post by **VL400** » Sat Apr 04, 2009 11:55 am

Yep your onto it, its a write enable jumper - with the jumper on it allows write mode. Both NVRAM boards have this now. Once your done making changes for awhile just remove the jumper to hopefully stop the NVRAM from becoming corrupt for no reason.

monaro308 · Post by **monaro308** » Sat Apr 04, 2009 12:33 pm

Thats some good stuff you have there VL400.
Are you making these boards or sourcing them from elsewhere?
Even though i have an Ostrich2 and a couple of VR ecu's and a 165ECM to fall back on,the 8192 ALDL board for the 808 will be a big winner as even a milkbar will have an 808 ECU lying around somewhere.

Also hanging on to the old serial laptop has it benifits too.
With the soon to be released Tunerpro RT V5 your timing might be spot on .
Good luck with it.
