READING STOCK EPROMS

[mattyc]

Hi guys,

ive got my moates gear this week and trying to read some stock eproms, i can seem to figure out how to read the 32pin eproms,

I have a vs supercharged v6 memcal here and some vs/vt v6 ones also, i can work out the file size etc when reading them,

do i have to change the addressing file codes?

im using a burn 2 and the moates flash & burn program

any help?

cheers

[Dec_head]

I don't think it supports them they are 27c1001 from memory and the moates burn 2 only supports AT29C256, 27SF512, and AM29F040 chips.
wich acccording to their website replace (2732A, 27C128/256/512/etc)

[mattyc]

so what am i requiring to be able to read and write the vs-vt eproms with?

thanks

[Holden202T]

i thought the vs ones were 27c010 ?

[Dec_head]

lol probably are 010 knew it was something like that wasn't sure and 2 lazy to look it up.
get a willem they support pretty much everything .

[antus]

1001 and 010 and most chips with a combination of 0s and 1s in the name are the same thing, its just different manufacturers codes. All mean 1 mbit, which is 128k byte. the ones with 4s are 4mbit, which is 512k byte.

[mattyc]

where is the best place to buy a burner from to do the vs-vt memcals?

[Dec_head]

This type supports all commodores memcals and more like the nvram described on this site pretty much everything

i recently updated to one of these and think it was money well spent

http://cgi.ebay.com.au/True-USB-Willem- ... 483aeadf6f

or a cheaper alternative wich i had for several years

http://cgi.ebay.com.au/Willem-Universal ... 2ead8586a3

[mattyc]

so what program is needed to be downloaded to use the willem programmer? i might just have to buy me one.

[yoda69]

Go to http://www.mcumall.com for product info and software.
I use the GQ-4X as well and find it a great little unit.

yoda69
